150x75x55x2.5 mm sliding point bracket
- Graphic
- 3D Model
Product description
This 150 mm long sliding point bracket is a structural, load-bearing component of RENOVENT rainscreen system. The bracket is fixed to the building wall with a single anchor to transfer wind loads from the rainscreen aluminium subframe.
aluminium alloy
niemalowane
System elements
150x100x55x2.5 mm fixed point bracket
200x100x55x2.5 mm fixed point bracket
240x100x55x2.5 mm fixed point bracket
105x58x5 mm thermal break for fixed point bracket
200x75x55x2.5 mm sliding point bracket
240x75x55x2.5 mm sliding point bracket
78x58x5 mm thermal break for sliding point bracket
60x45x1.8 mm 3 m ALU L-profile
